Alvolta 50A Manual Reset Circuit Breaker
Surface mount circuit breaker with 1/4" terminal studs
| Brand: Alvolta |
Alvolta 50 A Manual Reset Circuit Breaker
Features
- 50 A
- Manual reset circuit breaker
- Surface mount for simple on-wall installation
- Suitable for 12 - 48 V systems
- Marine-rated
- Suitable for heavy-duty applications
- IP67 rated thermoplastic
- Can be used as an ON / OFF isolation switch
- 1/4" / M6 terminal studs
- Thermal trip with trip status indicator
- Manual trip button
- Single pole
- Ignition protected
- Recessed mounting holes for tidy installation
Where to use it
Alvolta surface mount circuit breakers are ideal for under bonnet applications. They are suitable for use in motorhomes, 4WD, boats, marine, and off-grid setups.
Its durable design and IP67 rating make these an excellent choice for heavy duty, off-road applications. It is sealed internally against moisture, dust, and dirt.
Dimensions
Width | 48.2 mm |
Height | 57 mm |
Depth | 44 mm |
Weight | 0.1 kg |
Compliance
- SAE J1625
- ABYC E-11
- CE
- SAE J1117 (Ignition protection)
- IP67
Warranty
- 5-year warranty
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
