Alvolta 150/40 Touch Screen MPPT Solar Controller

40 A solar charge controller for 12-48 V systems

SKU: ACS40

Category: Solar Controllers , MPPT Charge Controllers , Solar Controllers , MPPT Charge Controllers

MPPT features

Maximum Power Point Tracking (MPPT) Technology
40 A rated charge current
98% efficiency
Maximum solar input voltage of 150Voc
Supports parallel charging
Integrated temperature compensation
Lithium recovery mode
Suitable for 12/24/36/48 V systems

Unit features

Die-cast aluminium casing
Tempered glass front
Magnetic terminal cover
Touch screen operation
LCD display screen
LED status indicators
Built-in Bluetooth

Compatible battery chemistries

Lithium
Flooded
Sealed lead acid
GEL

Where to use it

Designed to harness and optimise the power generated by your solar panels, this MPPT solar controller serves as an efficient mediator between your solar panels and your battery storage. It optimises the voltage and current from your solar panels, ensuring a faster and more effective battery charge.

Ideal for 4WDs, RVs, caravans, camper trailers, and other portable solar setups where every watt counts.

Dimensions

Width	190 mm
Height	120 mm
Depth	60 mm
Weight	1.89 kg

Warranty

3-year warranty

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

About Alvolta

Australian-owned and operated and driven by a passion for excellence, Alvolta offers unwavering performance and durability even in harsh Australian conditions. Alvolta specialises in precision-engineered DC components, designed to enhance off-grid adventures. Their commitment to delivering superior power performance with uncompromising quality is evident in their lineup of solar panels, solar charge controllers, circuit protection devices, mounting solutions, tools, and more. Supply yourself with all the arsenal you need to extend your power supply and adventure for longer with Alvolta.

Datasheet_ACS40_150-40-MPPT-Solar-Controller.pdf

Download

A solar charge controller regulates the voltage and current coming from your solar panels to your battery. It ensures the battery is charged safely and efficiently, prevents overcharging, and stops power from flowing backward from the battery to the panels at night.

A PWM (Pulse Width Modulation) controller is a simpler, cost-effective option suited for smaller systems, while an MPPT (Maximum Power Point Tracking) controller is more advanced and can convert excess panel voltage into additional charging current - improving efficiency by up to 30%.

Choose a controller that matches your system voltage (e.g., 12V, 24V, or 48V) and can handle the total current (amps) from your solar panels. Always allow some headroom - selecting a model rated about 25–30% higher than your maximum expected solar current for reliable performance and longevity.

Install the controller in a cool, dry, and well-ventilated area that is as close to the batteries as possible to minimise voltage drop. Avoid direct sunlight, water exposure, or enclosed spaces that could cause overheating and reduce performance.

Yes. The Alvolta charge controllers include built-in LCD screens and Bluetooth connectivity for app integration to show key system data such as charging current, battery voltage, and solar input power. This helps monitor system health and optimise your energy performance.

Product Specifications

Amperage	40A
System Voltage	12 V, 24 V, 32 V, 48 V
Standby Load	12 mA/12 V, 10 mA/24 V, 8 mA/32 V, 6 mA/48 V
Maximum Solar Input Voltage	<150 Voc
Maximum Solar Input	600 W/12 V, 1200 W/24 V, 1800 W/32 V, 2400 W/48 V
Operating Temperature	-35°C - +45°C
Terminal Capacity	16 mm²
IP Protection	IP34
Weight	1.89 kg
Dimensions	218 x 150 x 65 mm
Warranty	3 Years
