Alvolta Terminal Mount ST Blade Fuse Panel 4 Circuit Kit
Terminal-mounted fuse panel for standard blade fuses with blade fuses and ring terminals included
Alvolta Terminal Mount Fuse Panel 4 Circuit
Features:
- Fuse panel for standard blade fuses
- Easily mounted to a battery terminal
- 4 individual 30 A circuits
- M4 stainless steel terminal posts
- Sealable protective cover
- Maximum input voltage 32V DC
- Maximum input current 100 A
- Fuses and mounting screws included
What's included?
- Fuse panel
- 4x ATO fuses
- 4x 14-16 AWG nylon-insulated ring terminals
- 4x 10-12 AWG nylon-insulated ring terminals
- Sealable protective cover
Where to use it
Designed to add multiple fused circuits directly to a battery terminal, this fuse panel is ideal for RVs, 4WDs, campers, boats, and construction vehicles. This fuse panel allows up to 4 accessories to be connected directly to the battery through individually fused circuits, providing power and circuit protection to each accessory.
Dimensions
Length | 91.3 mm |
Width | 43.8 mm |
Height | 32.5 mm |
Weight | |
Compliance
- CE ROHS
Warranty
- 5-year warranty
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
About Alvolta
Australian-owned and operated and driven by a passion for excellence, Alvolta offers unwavering performance and durability even in harsh Australian conditions. Alvolta specialises in precision-engineered DC components, designed to enhance off-grid adventures. Their commitment to delivering superior power performance with uncompromising quality is evident in their lineup of solar panels, solar charge controllers, circuit protection devices, mounting solutions, tools, and more. Supply yourself with all the arsenal you need to extend your power supply and adventure for longer with Alvolta.
Datasheet_ATM4C_V2_compressed.pdf
Download
